2500 Tons Hydraulic open die forging press Japan Steel Works Ltd. (JSW)

Stock #502043

Overview

Type	Open die forging press
Manufacturer	JSW
Model	2500 MT
Year of manufacture	1987
Overhaul	1999
Press Specifications
Capacity	2500 tons (300 kg/cm²)
Upsetting Force at Static Working Pressure	25 MN (234 bar)
Stroke	1000 mm
Press Daylight	2489 mm
Distance Between Side Flame	1549 mm
Number of Pull Back Cylinder	1
Allowable Eccentric Load at 25 MN	200 mm radius
Forging Tolerance Measure on Hot Workpiece	±1 mm
Die Table Area (Width x Length x Stroke)	1400 x 3365 x 1500 mm
Press Speeds
Forging & Upsetting at 25 MN	58 mm/sec
Advance Speed, Fast/Slow	250/10 mm/sec
Die Table Slide Forward, Fast/Slow	250/5 mm/sec
Press Forces
Forging & Upsetting at 234 bar	25 MN (2500 tons)
Return at 234 bar	3.5 MN (350 tons)
Table Shift at 234 bar (Forward)	0.6 MN (60 tons)
Table Shift at 234 bar (Back)	0.4 MN (40 tons)
Hydraulic Pumps (Main)
Type	Axial Piston Pump
Quantity	4 sets
Pressure Rate	400 bar
Working Pressure	350 bar
Model	Rexroth (A2F500, A2F125)
Total Flow	2500 ℓ/min (315 bar)
Electric Main Motors
4 sets	300 KW, 6P, 3300 volt, 60 Hz, IP54, F class, Single end shaft
Total Electric Power Supply	1377 KW
Forklift Manipulator
Type	Used Doosan or Daewoo 16 (15) Ton Forklift Type Manipulator
Model	D160S-5
Year of Manufacture	2007
Actual Loading Capacity	5 Ton
Length	6065 mm
Width	2490 mm
Height	3170 mm
Gross Weight	18.9 tons
Driving Type	Self-propelled (Tire Type)
Rated Power	160/2100 PS/RPM
Number of Cylinders	6
Fuel Type	Diesel
