Heng Lorne Auto Thread STY-600HS High Strength Steel Compact Feedline

Heng Lorne Auto Thread STY-600HS High Strength Steel Compact Feedline

Brand
HENG LORNE

Model
STY-600HS

Type
Coil Feed Lines

Stock #
501541

Condition
Used

Year
2022

Location
Wayne, Michigan
United States

Request a Quote

SPECIFICATIONS
FILES & ATTACHMENTS

Max Weight of Coil	5000 kilograms
Max Coil Width Capacity	600 millimeters
Max Dia. of Coil	1500 millimeters

Equipped With

Maximum Width - 600 mm / 24"
Thickness range - 0.5~4.5 mm / 0.02"~0.177"
Coil Weight - 5000 KGs / 11000 LBs
OD - 800~1500 mm / 31"~60"
ID - 470~520 mm / 18.5"~20.5"
Hydraulic Mandrel Expansion
Straightner adjustment - Hydraulic
Bckup Rolls (Top and Bottom)
Hydraulic Passline Adjustment
Mitsubishi Controls
Speed - 16m/min / 630 in/min
Robust contruction
Compact Footprint
Automatic Coil Threading
High Strength Material
