Equipped With
Bed Size: 67'' x 60''
Year: 1964
Stroke: 36''
Shut height: 48''
Ram Area: 60'' x 60''
T-Slotted Bolster: 11.5''
T- Slotted Ram
24" Wide x 30 Tall Windows
Diameter Cylinder: 20"
CUSHION: 46" x 46" Cushion Pad
Cushion Stroke: 12"
Hydraulic mount on top of press removable
Adjustable tonnage
Advance Speed: 440 IPM
Pressing Speed: 65 IPM
Return speed: 458 IPM
2 Motors: 100 HP, 50 HP, 220/440 VOLTAGE, 1770 RPM
Good condition
Approximate Dimensions: 108" LR x 84" FB x 22'6" TALL
Approximate Weight: 140,000 LBS
