Equipped With
Tonnage: 330T
Stroke: 7.87"
Shut Height: 21.65"
Bed Area (Left to Right): 96.5"
Bed Area (Front to Back): 47.2"
SPM Min: 40
SPM Max: 100
Adjustment: 3.94"
Windows Width: 48"
Slide Area: 96.5" x 47.2"
Air Clutch: Yes
Vari Speed: Yes
Crank: Double
Year: 2006
Equipped with:
Air Clutch and Brake Assembly
Air Counterbalances
T-slotted Bolster and Ram
Trabon Recirculating Lubrication System
Free Standing Console Press Control
Wintriss Smart Pac 2 Press controls
Set of Light curtains
Vibration Isolation Levelers
Hydraulic Overload Protection
Dynamic Balancing of Slide and Upper Die
Power Requirement: 480/3/60
