Overview
- Make
- KOMATSU
- Model
- HF4-600
- Type
- Servo Presses
- Year
- 2002
- Condition
- Not specified
- Stock #
- 502068
Spec Sheet
MODEL #: HF4-600
SERIAL #: 10001
11.81" STROKE
45.26" SHUT HEIGHT
11.81" SLIDE ADJUSTMENT
196.8" x 62.98" BED
196.8" x 62.98" RAM
84" WINDOWS
OVER DROP DISTANCE 150mm
STOPPING TIME 470ms
MAXIMUM STOPPING TIME 495ms
26,458 LBS ALLOWABLE UPPER DIE MASS
MANUFACTURED 2002 INSTALLED 2003
SERVO DRIVE
KOMATSU TRANSFER SYSTEM
MODEL TMF63-3D
SERIAL #: 10001
11.81" STROKE
45.26" SHUT HEIGHT
11.81" SLIDE ADJUSTMENT
196.8" x 62.98" BED
196.8" x 62.98" RAM
84" WINDOWS
OVER DROP DISTANCE 150mm
STOPPING TIME 470ms
MAXIMUM STOPPING TIME 495ms
26,458 LBS ALLOWABLE UPPER DIE MASS
MANUFACTURED 2002 INSTALLED 2003
SERVO DRIVE
KOMATSU TRANSFER SYSTEM
MODEL TMF63-3D
