Year: 1995
Press Force: 16,000 kN
Maximum Press Force Station 1-5: 4,000 kN
Stroke Height: 1,000 mm
Energy Consumption: 400 k.J
Stroke Frequency (Automatic): 10 - 25 strokes/min
Stroke Frequency (Setting): 4-10 strokes/min
Distance between Bolster Table and Ram (bottom): 1175 mm
Distance between Bolster Table and Ram (top): 800 mm
Ram Length: 50 mm
General Information about the Transfer:
Transfer Bars in Closed Position (min. - max.): 850-2120 mm
Open/Close Transfer Bars: 250 mm
Transfer Bar Lift Height: 150 mm
Minimum Distance Bolster Table Top - Bottom of Transfer Bar: 590 mm
Maximum Weight Fingers/Grippers (excl. Details): approx. 150 kg
General Information about the Air Cushion in the Bed Station (Station 1)
Press Force Air Cushion at 14 bar: 1500 kN
Air Cushion Stroke Height: 150 mm
