| Tonnage | 1500 tons |
| Bed Size | 132'' x 60'' |
Bed Size: 132'' x 60''
Adjustment: 12''
Shut Height: 48''
Stroke: 16''
SPM: 10-20
Width between uprights: 134''
Steel bolster plate thickness: 10''
Opening in uprights, FB x TB: 52'' x 48''
Distance from floor to top of bed: 15.5''
Distance from top of bed to mounting feet: 36''
Distance from floor to top of press: 316.5''
Distance from floor to bottom of press: 79''
Project floor area: 285'' x 160''
Press Weight: 490,000
Net weight: 535,000
